Selection Guide for Optical Modules with High TemperatureResistance in Tropical Regions

 In network infrastructure projects in developing countries, we observed that: ＞73% of purchasing man...

Learn more

Maintenance/Installation

Illustrated Guide to Cleaning Optical Modules Without Professional Tools

Learn more

Other

The Impact of Module Compatibility on Operational Expenditure (OPEX)

Learn more
PERHAPS YOU'RE SEEKING SOMETHING LIKE THIS
By Industry
By Scenario
Trunk transmission
Data Center
Network Cabling
RELEVANT PRODUCTS85,87,90,91
  • Copper SFP

    Port Type：RJ-45 Port

    Rate：1000M, 10/100/1000M

    ：

    Learn more
    • Up to 1.25Gb/s data links
    • Hot-pluggable SFP footprint
    • Fully metallic enclosure for low EMI
    • Low power dissipation (1.05 W typical)
    • Compact RJ-45 connector assembly
    • Access to physical layer IC via 2-wire serial bus
    • 1000 BASE-T operation in host systems with SERDES interface
    • 10/100/1000Mbps or 1000Mbps compliant in host systems with SGMII interface
    • Operating case temperature: Standard:  0 to +70°C
  • 1.25G Dual Fiber SFP

    Wavelength：850nm,1310nm, 1550nm

    Distance：550m,2km,10km,20km,40km,80km,120km,Customized

    Port Type：LC Port

    Learn more
    • Dual data-rate of 1.25Gbps/1.063Gbps operation
    • 850nm VCSEL laser transmitter and PIN photo detector for 550m transmission
    • 1310nm FP laser transmitter and PIN photodetector for 10km/20km transmission
    • 1550nm DFB laser transmitter and PIN photo detector for 80km transmission
    • 1550nm DFB laser transmitter and APD photo detector for 120km transmission
    • Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
    • Hot-Pluggable
    • Digital Diagnostic Monitoring
    • Compatible with SONET OC-24-LR-1
    • Compatible with RoHS
    • +3.3V single power supply
    • Operating case temperature: Standard:  0 to +70°C
  • 1.25G BiDi SFP

    Wavelength：Tx1310nm/Rx1550nm, Tx1550nm/Rx1310nm,Tx1490nm/Rx1550nm,Tx1550nm/Rx1490nm, Tx1310nm/Rx1490nm,Tx1490nm/Rx1310nm

    Distance：2km,10km,20km,40km,80km,120km,Customized

    Port Type：LC Port, SC Port

    Learn more
    • Dual data-rate of 1.25Gbps/1.063Gbps operation
    • 1310nm FP laser transmitter and 1550nm PIN photo-detector for 10/20km transmission
      1310nm DFP laser transmitter and 1550nm PIN photo-detector for 40km transmission
      1550nm DFB laser transmitter and 1310nm PIN photo detector for10/20/40km transmission
      1490nm DFB laser transmitter and 1550nm APD photo detector for 80km/120km transmission
      1550nm DFB laser transmitter and 1490nm APD photo detector for 80km/120km transmission
    • Compliant with SFP MSA and SFF-8472
    • Hot-Pluggable
    • Digital Diagnostic Monitoring
    • Compatible with SONET OC-24-LR-1
    • Compatible with RoHS
    • +3.3V single power supply
    • Operating case temperature: Standard:  0 to +70°C
  • 2.5G Dual Fiber SFP

    Wavelength：850nm,1310nm, 1550nm

    Distance：550m,2km,10km,20km,40km,80km,120km,Customized

    Port Type：LC Port

    Learn more
    • Up to 2.67Gb/s Data Links
    • 850nm VCSEL laser transmitter for 300m transmission
    • 1310nm FB laser transmitter for 10km/20km transmission
    • 1310nm DFB laser transmitter for 40km transmission
    • 1550nm DFB laser transmitter for 40km/80km/120km transmission
    • Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
    • Hot-Pluggable
    • Digital Diagnostic Monitoring
    • Compatible with RoHS
    • +3.3V single power supply
    • Operating case temperature: Standard:  0 to +70°C
AFTER-SALES SERVICE
The laser, golden finger, and lens of the optical module all come with a one-year warranty.
